Segate 1 Tbb Ssd Harici 2.5 Hdd Full Set

Seagate Laptop SSHD Specifications

• Form factor: 9.5mm (7mm for 500GB)
• Model Name: Laptop SSHD
• Capacities: 1TB, 500GB
• Standard Model: ST1000LM014
• Self-Encrypting Drive (SED) Model: ST1000LM015
• SED-FIPS 140-2 Model: ST1000LM028
• Interface: SATA 6.0/3.0/1.5Gb/s NCQ
• Performance Versus 2.5-in. 5400-RPM/7200-RPM HDD:
  • Windows 7 Boot Time: 35% Faster/25% Faster
  • Applications Load Test: 450% Faster/300% Faster
  • Game Load Test: 140% Faster/50% Faster
• Configuration/Organization
  • Heads/Disks: 4/2
  • Bytes per Sector: 4096
  • Power Supply Requirements: +5V
  • Reliability/Data Integrity:
  • Head-Rest Method: QuietStep Ramp Load
  • Load/Unload Cycles: 600,000
  • Nonrecoverable Read Errors per Bits Read, Max: 1 per 10E15
  • Predicted Annualized Failure Rate (AFR): 0.48%
• Power Management
  • Power, Seek, Typical (W): 2.7
  • Power, Idle, Typical (W): 0.9
• Environmental:
  • Temperature, Operating (°C): 0 to 60
  • Temperature, Nonoperating (°C): −40 to 70
  • Shock, Operating: 2ms (Gs): 350
  • Shock, Nonoperating: 1ms (Gs): 1000
  • Acoustics, Idle, Typical (bels—sound power): 2.2
  • Acoustics, Seek, Typical (bels—sound power): 2.7
• Physical
  • Height (mm/in, max), Standard and SED Models: 9.5/0.374
  • Height (mm/in, max), FIPS Model: 9.5/0.374
  • Width (mm/in, max): 69.85/2.75
  • Depth (mm/in, max): 100.35/3.95
  • Weight (g/lb): 115 /0.25 4
• Limited Warranty (years): 3
